Preface

Starting with Release 2025, only 64-bit versions of CAD6 are available.

This manual describes all elements and commands of CAD6studio. The additional CAM Part of CAD6industrie is described in the CAD6 Online CAM Manual. All further plug-ins (see also Import and Export Filters) are described in separate manuals which are not available online.

You can call the manual from within Malz++Kassner CAD6 by choosing the Help > CAD6 Manual command. In addition, you can press the F1 Key at any time in Malz++Kassner CAD6. This displays the topic corresponding to the current command or dialog. This ensures that you get the required information quickly and easily, without time consuming page turning and searching indexes and tables of contents - just a simple keypress!

Contact

For technical support and any other questions please send an e-mail to post@malz-kassner.com. On our website www.CAD6.com you can find the latest application versions and upgrades, and current information on our products.

Malz++Kassner GmbH

Am Westerberge 46

38122 Braunschweig

Germany

Phone +49 531 400 137

Fax +49 531 400 138

www.CAD6.com

post@malz-kassner.com

All graphics and tables used in this document were generated with Malz++Kassner CAD6 and exported as PNG file. Markings are output as crosses, in order to generate the point markings quickly and easily.

All trademarks are trademarks or registered trademarks of the respective owner, they are only used for information. Malz++Kassner is a registered trademark of Malz++Kassner GmbH in Germany. Revision 2025-03-18.
