413: 3D Pins DIN 1, 7 + Counterbores DIN 74 (Standard Libraries)

Author: Michel Christiaens

Library Content "(3D) Taper Pins DIN 1"

Bottom View\Ø1.5\lg10..lg30

Bottom View\Ø1\lg10..lg20

Bottom View\Ø10\lg40..lg100

Bottom View\Ø12\lg36..lg100

Bottom View\Ø16\lg60..lg100

Bottom View\Ø2.5\lg12..lg50

Bottom View\Ø2\lg10..lg50

Bottom View\Ø3\lg12..lg60

Bottom View\Ø4\lg16..lg100

Bottom View\Ø5\lg20..lg100

Bottom View\Ø6\lg24..lg100

Bottom View\Ø8\lg28..lg100

Top View\Ø1.5\lg10..lg30

Top View\Ø1\lg10..lg20

Top View\Ø10\lg40..lg100

Top View\Ø12\lg36..lg100

Top View\Ø16\lg60..lg100

Top View\Ø2.5\lg12..lg50

Top View\Ø2\lg10..lg50

Top View\Ø3\lg12..lg60

Top View\Ø4\lg16..lg100

Top View\Ø5\lg20..lg100

Top View\Ø6\lg24..lg100

Top View\Ø8\lg28..lg100

Library Content "(3D) Straight Pins DIN 7"

Ø10\lg16..lg100

Ø12\lg24..lg120

Ø2.5\lg10..lg20

Ø2\lg10..lg24

Ø3\lg10..lg30

Ø4\lg8..lg50

Ø5\lg10..lg60

Ø6\lg10..lg80

Ø8\lg10..lg120

Library Content "(3D) Counterbores DIN 74"

Form A\Average (m)\Ø1.6....Ø20

Form A\Fine (f)\Ø1.6..Ø20

Form B\Average (m)\Ø3..Ø24

Form B\Fine (f)\Ø3..Ø20

Form H\Average (m)\Ø1.6..Ø24

Form H\Fine (f)\Ø1.6..Ø24

Form H1, J1, k1\Average (m)\Ø2..Ø24

Form H1, J1, k1\Fine (f)\Ø2..Ø24

Form H2, J2, K2\Average (m)\Ø4..Ø36

Form H2, J2, K2\Fine (f)\Ø4..Ø24

Form H3, J3, K3\Average (m)\Ø3..Ø36

Form H3, J3, K3\Fine (f)\Ø3..Ø24

Form J\Average (m)\Ø4..Ø36

Form J\Fine (f)\Ø4..Ø24

Form K\Average (m)\Ø1.6..Ø36

Form K\Fine (f)\Ø1.6..Ø24

Form R\Average (m)\Ø2..Ø36

Form R\Fine (f)\Ø10..Ø24

Libraries with the addition "3D" do not contain any 3D data, only an isometric view!
